Modern filter baskets have enabled a dramatic leap in the extraction yields possible with espresso coffee. In the recipe, they have gone from being a fairly hum-drum accessory to becoming perhaps among the the majority of important pieces of device on your bar. In our last post, we bench-tested a few recent designs, and saw for ourselves how this seemingly modest technology can transform the extraction efficiency and the flavour of our shots.

The defining feature of this new wave of high extraction filter baskets is the pattern of holes at the bottom of the basket. Manufacturers have entirely re-thought the way these are laid out, to ensure even extraction right up to the edges of the puck, and to enable faster flow through the coffee bed. In turn, this allows the barista to utilize finer grind sizes and achieve considerably higher extraction yields. But, to judge by their hole patterns, the baskets we tested take radically different — and seemingly contradictory — approaches to maximising flow.

Different hole patterns in baskets

To try and understand this contradiction, we reached out to Professor Abbott for help in analysing the hole patterns of our filter baskets. He responded by creating a brand-new app for us — the Basket Hole Analyser.

Armed with this app, you can analyse the size distribution, hole placement, and the total open area of the holes at the bottom of your basket. You can likewise verify for yourself some of the claims that manufacturers make about their baskets. Are your baskets truly identical? And how much variation in size is there from one hole to the next?

Professor Abbott’s app builds on earlier work by Robert McKeon Aloe — take a look at these fascinating posts where he compares the build quality of different baskets. The app uses much the same technique as McKeon Aloe’s analyses, but enables anyone to do this sort of analysis for themselves. We’ll explain how to get the perfect possible impacts from the app later on. in this post — however first, let’s explore some of the results of our measurements.

The Paradox of Modern Baskets

The impacts of our tests of modern filter baskets were really clear: the new designs allow higher flow rates and hence, higher extractions. What surprised us, but, is that the baskets achieved this in really different ways. The Sworks Billet baskets enable fast flow by having large numbers of tiny holes, while the Pesado HE% baskets rely on large, closely-packed holes to maximise the open area at the bottom of the baskets.

Sworks Billet basket (left), Pesado HE% basket (right)

Analysing the baskets we tested in the app, we can see that the tiny holes of the Sworks Billet basket make for a total open area of 4% — barely more than the IMS baskets we used as a baseline. The large holes of the Pesado, on the other hand, make up an extraordinary 14% of the total basket area. These two baskets get quite similar results, in strikingly different ways.

You might expect that the different hole sizes and open area of the baskets would result in them putting up different amounts of resistance to the flow of espresso coffee — but actually, that seems to be of little importance. The reason for this is that the resistance to flow from the puck is much bigger than the resistance to flow from the basket itself, so the basket resistance brews only a small difference to the total.

To put this in mathematical terms, the total flow rate (T_b) through in an espresso coffee can be given as frac1T_t = frac1T_b + frac1T_c, where Tb is the flow rate you would get through the basket alone, and T_c is the flow rate you would get through the coffee puck. Since the flow rate through the basket with no coffee in (T_b) is much higher than the flow rate through the coffee puck would be (T_c), changing the flow rate through the basket has really little effect on the overall flow rate.

So it seems that the high flow from modern baskets isn’t due to the fact that they themselves have low resistance, Instead, the basket design seems to interact with the puck itself — partly because the baskets allow flow much closer to the edge of the puck, however perhaps likewise due to the truth that the design of the holes somehow prevents them from getting clogged by coffee particles.

Exploring Basket Quality

As well as showing the hole size and total open area, the app also lets us see how even the size and spacing of the holes in a basket are. It seems reasonable to assume that the more uniform the holes, the more even the extraction across the puck.

With the app, you can visualise the differences in hole size and spacing across a basket, represented by the holes being given different colours. When we plug in our photos of the Sworks and Pesado baskets, we can see that the size of the holes is fairly even in each, as you would expect from well-made baskets.

In Location Variance mode, nevertheless (enabled by checking the box marked ‘L-Variance’), you can see a conspicuous difference between the designs. The Sworks holes are placed in a Fibonnaci spiral, so that the spacing between holes is extremely similar all the way across the basket. The Pesado holes, on the other hand, are placed in concentric rings. The hole spacing in each ring is measurably different, resulting in a riot of colour in the app. What effect on this might have extraction quality remains to be determined.

How to Photograph Your Baskets

If you want to work with the app to check on the build quality of your own baskets, the hardest part — and by far the most important — is getting the picture right. As Professor Abbott puts it, “image analysis is 10% the analysis and 90% the image”.

The app needs a high-contrast photo of the inside of the basket, with the holes backlit, and no other light or reflections visible. To get this kind of picture, you’ll need a high-resolution camera, ideally with a telephoto macro lens, and a tripod that allows you to position the camera vertically over the basket. With a wide angle lens such as a phone camera, the holes at the edge of the basket may appear smaller than the holes in the middle, due to the truth that of the angle the light must pass through to reach the lens.

Take special care to align your camera well before shooting your basket

Place the basket (with the bottom facing down) onto a backlit surface. A lightbox would be ideal, nevertheless you could also use an iPad or phone screen with a white background. To eliminate light seeping in from the sides, cover the rest of the screen with cardboard, with a hole cut in it so that it only allows light in through the basket holes.

Place the camera on a tripod, and aim it down vertically at the basket. Work with a spirit extent to ensure that the camera is pointing directly downwards. If you are able to adjust the settings on your camera, utilize a narrowed aperture (F8 or less) to ensure a high depth of field; you may need to slow down the shutter speed to capture enough light.

Before taking the shot, you’ll also need to ensure that no external light is coming in by darkening the room or covering the camera with a sheet. If you are utilizing a slow shutter speed, do your perfect to avoid creating any vibration that could affect the shot.

Take multiple shots of each basket, rotating the basket in place every time. If you see that one side of the basket has smaller holes than the other, this can be an artefact of the camera angle not being totally vertical. Rotating the basket will let you check if any differences in hole size you see are due to the camera angle, or a genuine difference in the basket holes.

Larger holes on one side of the basket could be a manufacturing error, however is more likely to be an artefact of the lens being positioned closer to that side of the basket. To determine if it is an artefact or a genuine difference, take numerous images and rotate the basket each time.

The last step is to check the size of the basket base. The easiest way to do this is to replace your brew basket with a ruler, positioned so that the scale lines up with where the centre of the basket had been. Without making any adjustments to the camera, take a picture of the ruler, and compare this image to the pictures of your basket in order to gauge the size of the basket base.

Alternatively, you could try pressing paper into the bottom of the basket and taking a measurement from that, or even turning out a dry puck from the basket and measuring the bottom of that. Don’t get too hung up about this measurement, nevertheless. As Professor Abbott explains: “Uniformity and reach up to the edge are more likely to be important [than the exact size], so we don’t have to stress too much.”

Once you’ve taken the photographs, work with an picture editor such as Photoshop to remove any reflections that did sneak into the picture. Crop the picture so that the edges of the photo line up exactly with the bottom of the basket. Finally, increase the contrast to maximum, and the image is ready to upload to the app.

An Alternative Approach

Another way to get a image of the basket holes is to work with a flatbed scanner. This will only work well if the base of the basket is perfectly flat. Lots of baskets become slightly bowed out after work with, so it’s perfect to use this approach with brand-new baskets only.

Place the basket directly onto the glass plate (scan bed). Lay a couple of layers of baking paper on top of the basket to diffuse light. Hold a potent flashlight about 30cm above the basket, and start the scan.

Once you have loaded the scan onto your computer, open it up in Photoshop and lower the midtone levels and increase contrast as much as possible. Then tidy up the picture by selecting all the individual holes with the magic wand tool (a tolerance of 10–12 worked well for us) and filling in the rest of the space with black to eliminate any reflections on the basket itself.

Handling Blocked Holes

Some modern baskets seem to be especially prone to becoming blocked by coffee particles. If you want to try and clear these blockages out before taking a photo, then McKeon Aloe suggests trying compressed air, an acupuncture needle, or even an ultrasonic cleaner, depending on the basket design.

For our analyses, where we did find a blocked hole, we literally replaced it with an unblocked one in Photoshop. It’s pretty much unheard-of for modern baskets to have unpunched holes, so we’re confident that any time a hole doesn’t show up on our picture, it’s either a blockage or some other artefact.

But, Abbott’s advice is just not to fret too much: “In terms of information. analysis of open area, I don’t think a blocked hole matters a damn,” he says. “If 1000 holes have an open area of 2.00% then an analysis with 5 holes blocked gives an area of 1.99%. Errors in lighting/thresholding are likely to give differences larger than that.”

Analysing Your Baskets

Once your image is ready, you need to upload your picture to the app, then enter the internal diameter of the basket. If you want to compare multiple baskets, then it’s required to work with the exact same setup for the photos of each one. Even minor differences in the angle or distance from the lens can affect the analysis, creating the comparison invalid. Keep this in mind if you are comparing your effects to ours (or anyone else’s).

Once you’ve plugged in your photos, then you can follow Professor Abbott’s instructions in this video to see the different data the app can pull from them.

[embedded content]

[embedded content]

For us, the data we get from the app in fact drive home how incredibly precise the manufacturing on the new wave of baskets is. The increase in extraction yields that this brews possible is substantial.

While a new set of baskets might seem like a big investment, compared to the low cost of traditional baskets, the high extraction implies that you can use slightly less coffee to make espresso at the same strength — and get tastier shots to boot. When you calculate it this way, a busy cafe can make up the cost of a pair of 200 dollar baskets fairly quickly.

If you’re not convinced, try utilizing the app to analyse the baskets you’re currently using. How evenly sized are the holes? How much of the edge of the puck isn’t getting extracted correctly, because the holes don’t reach there? Armed with this information, perhaps you’ll find it’s time to start raising your expectations of how well-made a basket must be.

Revolutionizing Espresso Extraction: The Power of Modern Filter Baskets

Ever wondered why your espresso flavors so good? Well, it’s not just about the coffee beans or the barista’s skills. A seemingly mundane piece of tool – the filter basket – plays a significant function in determining the quality of your espresso shot. Truly, modern filter baskets have become a game-changer in achieving higher extraction yields, transforming them from being an overlooked accessory to a pivotal part of your coffee bar.

A New Wave of High Extraction Filter Baskets

The secret sauce behind these high extraction filter baskets is their unique hole pattern at the bottom. Manufacturers have reimagined these designs to ensure even extraction right up to the puck’s edges and facilitate faster flow through the coffee bed. This creation allows baristas to utilize finer grind sizes and achieve drastically higher extraction yields.

However here’s where it gets interesting: different baskets employ radically different — and seemingly contradictory — approaches to maximising flow. Some utilize large numbers of tiny holes while others rely on large, closely-packed holes. It’s like comparing apples with oranges, yet they both make for a delicious fruit salad!

Knowledge Hole Patterns with Basket Hole Analyser

To unravel this mystery, we turned to Professor Abbott who created an ingenious app for us — the Basket Hole Analyser. This app lets you analyse hole size distribution, placement, and total open area at your basket’s bottom. You can even verify some manufacturers’ claims about their baskets! Are all your baskets truly identical? And how much variation in size is there from one hole to another?

The Paradox of Modern Baskets

The effects from our tests were clear as day: new designs allow higher flow rates and hence, higher extractions. But what surprised us was that different baskets achieved this in really different ways. For instance, the Sworks Billet baskets enable fast flow by having large numbers of tiny holes, while the Pesado HE% baskets rely on large, closely-packed holes.

Now, you might think that different hole sizes and open areas would result in varying resistance to espresso coffee flow. Nevertheless, it turns out that the resistance from the puck is much greater than from the basket itself. So, changing the basket’s flow rate has minimal effect on the overall flow rate.

So why do modern baskets have high flow? It’s not because they themselves have low resistance. Instead, it seems that the basket design interacts with the puck itself — partly due to the truth that they allow flow closer to the puck’s edge and perhaps also because their hole design prevents them from getting clogged by coffee particles.

Exploring Basket Quality

The Basket Hole Analyser likewise lets us see how even a basket’s hole size and spacing are. The more uniform these are, we can assume a more even extraction across the puck. When we analysed our Sworks and Pesado baskets utilizing this app, we found that both had fairly even hole sizes – a testament to their quality manufacturing.

How to Photograph Your Baskets for Analysis

If you’re keen on checking your own baskets’ build quality using this app, getting a high-contrast photo of your basket’s inside is crucial. You’ll need a high-resolution camera (ideally with a telephoto macro lens), a backlit surface (like an iPad or phone screen), and some patience!

Once you’ve taken your photos (remember to take multiple shots of each basket), work with an picture editor like Photoshop to remove any reflections and increase contrast to maximum. Now your photo is ready for upload into the app.

Analyzing Your Baskets

Once your photo is ready, upload it to the app and enter the basket’s internal diameter. The information. you get from this analysis will give you a new appreciation for the precision involved in manufacturing these baskets and the substantial increase in extraction yields they make possible.

While investing in a new set of baskets might seem like a big expense compared to traditional ones, their high extraction implies you can use mildly less coffee to make espresso at the same strength — and get tastier shots too! So, if you’re still on the fence, try utilizing this app to analyze your recent baskets. You might literally find it’s time to raise your expectations of how well-made a basket ought to be!
